Sigma Announces 24mm F2 and 90mm F2.8 DG DN Contemporary lenses

By on

Sigma launch two brand new lenses for Mirrorless users; the 24mm F2 DG DN Contemporary and the 90mm F2.8mm DG DN Contemporary.

The lenses, designed for E- and L-mount bodies, are all-metal and feature aperture rings and weather-sealing. Both will be available later this month for $639.

The 90mm F2.8 DG DN is a bit smaller than the 24mm, but it’s also a stop slower. It has a total of 11 elements, including one aspherical and five SLD elements. As with the 24mm F2, a stepping motor is used to drive the focus unit on the 90mm.

The minimum focus distance on this lens is 0.5m (19.7″), with a max magnification of 0.2x. The dimensions of the 90mm are 64x60mm for L-mount and 64x62mm for E-mount. Both weigh just 295 grams (10.4 ounces). The 90mm uses 55mm filters.

Sigma 90mm f/2.8 DG DN | Contemporary: B&H Photo / Amazon / Adorama
Sigma 24mm f/2 DG DN | Contemporary: B&H Photo / Amazon / Adorama

The all-new 24mm F2 DG DN | Contemporary delivers exceptional edge-to-edge rendering power in an ultra-compact, all-metal body. This impressive, wide-angle, I series prime is now available for L-Mount and Sony E-mount systems.

The 24mm F2 DG DN | Contemporary premium compact prime is the latest lens to be added to SIGMA’s growing I series range. It joins four existing I series lenses as well as the new 90mm F2.8, offering superb optical performance, a bright F2 aperture, an all-metal build and a manual aperture ring. Designed from the ground up for mirrorless systems it feels perfectly-balanced on modern full-frame bodies, and boasts exceptional resolving power that can keep up with the latest ultra-high-resolution cameras.

The lens’s advanced optical design produces sharp, high-contrast results from the center of the frame to the far corners, and together with its F2 aperture and wide angle-of-view it’s an excellent choice for night sky photography, events and interiors.

Owing to its compact size the lens can be carried around effortlessly, which makes it perfect for day-to-day use. The high quality, all-metal construction, which is found on all of SIGMA’s I series models, makes the experience of owning and operating this lens extremely satisfying.

This new full-frame 24mm F2 prime is designed for photographers who need a sharp, fast, robust, wide-angle optic that will not weigh them down. It is available for L-Mount and Sony E-mount systems.

Key features

1. I series – Premium Compact Primes for mirrorless users

The SIGMA I series features full-frame-compatible lenses that offer mirrorless users a new and better alternative, both in the experience of shooting with the lens and in the impressive results it is able to achieve.
One of the key advantages of mirrorless cameras is their smaller form-factor, and this new 24mm optic is designed to be perfectly matched to these more compact systems without sacrificing performance. This combination of superb optical quality with exceptional portability, not previously possible with DSLR systems, will bring new opportunities to this and future generations of photographers.
Simultaneously, SIGMA is aware that, in this day and age when we have such huge diversity when it comes to what we use to photograph, as represented by smartphones, people look for something more than a mere act of ‘taking pictures’ when they choose to own a camera and lenses.
SIGMA’s excellence in development and processing technologies has been built up since it was founded in 1961 – actually, this lens is being announced 60 years to the day since SIGMA’s story began – and has become further sophisticated with the introduction of the SIGMA Global Vision in 2012. With this as a base SIGMA has given careful thought to how photographers use and enjoy their lenses, including optical design, advanced functionality, build quality and the experience of picking up and using the lens, and with all of this carefully considered the I series was born.

2. New standards of optical performance for the Contemporary line
The SIGMA 24mm F2 DG DN | Contemporary, like the SIGMA 35mm F2 DG DN | Contemporary and the SIGMA 65mm F2 DG DN | Contemporary, combines the highest level of optical performance even at its maximum aperture of F2 and a well-balanced body.
The lens uses two SLD glass elements and one FLD glass element to correct axial chromatic aberration, which is a particular concern with bright lenses. It also incorporates two high-precision glass-molded aspherical elements, made possible by the processing technology of SIGMA’s sole production facility in Aizu. This has enabled the total number of lens elements to be kept down and the size and weight of the lens to be reduced, while providing excellent correction of various aberrations.
In anticipation of wide-angle lens applications, SIGMA’s optical designers have ensured the lens resolution is extremely high, and is uniform from the center to the periphery of the image. Sagittal coma flare is also well suppressed, giving the lens a high degree of rendering power that makes it ideal for night sky photography.
The AF drive system incorporates a quiet, high-speed stepping motor. This allows photographers to capture every detail of the spacious 24mm scene with light AF.

3. Exceptional I series build quality with a compact form-factor
All I series lenses have an all-metal construction. The precision-cut aluminum parts not only give the barrel a sleek, stylish finish, but provide superb durability that improves the quality of the entire product. Metal materials are also used in internal structures that slide with the operation ring for added robustness. These high-precision components crafted with SIGMA’s cutting-edge metalworking technology are also used in SIGMA’s cine lens line-up for professional cinematographers and provide a tactile, ergonomic feel that make the lens a pleasure to use.
The cover ring between the focus ring and the aperture ring has hairline processing that is also used for the rear cylinder of the Art line. This covering functions as a finger hold when attaching or detaching the lens.

Additional features
• Lens construction: 13 elements in 11 groups, with 1 FLD, 2 SLD and 2 aspherical lens elements
• Inner focus system
• Compatible with high-speed autofocus
• Stepping motor
• Compatible with lens aberration correction
* Function available on supported cameras only. Available corrections may vary depending on the camera model.
• Support DMF and AF+MF
• Super Multi-Layer Coating
• Aperture ring
• Focus Mode switch
• Petal-type lens hood (LH656-02)
• Magnetic metal lens cap (LCF62-01M)
• Mount with dust and splash resistant structure
• Compatible with SIGMA USB DOCK UD-11 (sold separately / for L-Mount only)
• Designed to minimize flare and ghosting
• Every single lens undergoes SIGMA’s proprietary MTF measuring system
• 9-blade rounded diaphragm
• High-precision, durable brass bayonet mount
• “Made in Japan” craftsmanship
Key specifications (The figures below are for L-Mount)
Lens construction: 11 groups, 13 elements (1 FLD, 2 SLD and 2 aspherical) Angle-of-view: 84.1°
Number of diaphragm blades: 9 (rounded diaphragm)
Minimum aperture: F22
Minimum focusing distance: 24.5cm
Maximum magnification ratio: 1:6.7
Filter size: φ62mm
Dimensions (Maximum Diameter x Length): φ70mm×72mm Weight: 365g

SIGMA’s brand new, mid-telephoto I series prime for mirrorless systems, the compact 90mm F2.8 DG DN | Contemporary premium compact prime, has also been added to SIGMA’s growing I series range. It joins four existing I series primes as well as the all-new 24mm F2, offering superb optical performance, a bright F2.8 aperture, an all-metal build and a manual aperture ring. Designed especially for mirrorless systems it feels well-balanced on modern full-frame bodies, and boasts exceptional resolving power that can keep up with the latest ultra-high-resolution cameras.

With its versatile mid-telephoto focal length, the lens is the longest I series lens yet, but still remains remarkably compact and light so is ideal for day-to-day use. It is fully-optimized for mirrorless systems with ultra-fast and accurate AF performance, and it boasts outstanding optical capabilities. The rich, smooth bokeh makes
for attractive backgrounds, which is perfect for portraits, and the minimum focusing distance of 50cm allows photographers to get closer to their subject.
This high-quality, everyday lens is able to bring scenes to life with its beautiful rendering and ultra-sharp optics, all in a portable, robust and tactile lens body.

Key features

1. I series – Premium Compact Primes for mirrorless users

The SIGMA I series features full-frame-compatible lenses that offer mirrorless users a new and better alternative, both in the experience of shooting with the lens and in the impressive results it is able to achieve.
One of the key advantages of mirrorless cameras is their smaller form-factor, and this new 90mm optic is designed to be perfectly matched to these more compact systems without sacrificing performance. This combination of superb optical quality with exceptional portability, not previously possible with DSLR systems, will bring new opportunities to this and future generations of photographers.
Simultaneously, SIGMA is aware that, in this day and age when we have such huge diversity when it comes to what we use to photograph, as represented by smartphones, people look for something more than a mere act of “taking pictures” when they choose to own a camera and lenses.
SIGMA’s excellence in development and processing technologies has been built up since it was founded in 1961 – actually, this lens is being announced 60 years to the day since SIGMA’s story began – and has become further sophisticated with the introduction of the SIGMA Global Vision in 2012. With this as a base SIGMA has given careful thought to how photographers use and enjoy their lenses, including optical design, advanced functionality, build quality and the experience of picking up and using the lens, and with all of this carefully considered the I series was born.

2. New standards of optical performance for the Contemporary line

The SIGMA 90mm F2.8 DG DN | Contemporary boasts exceptional optical performance with a ultra-high resolving power to match the latest high-resolution mirrorless cameras.
The lens is built using the very latest optical technology, and includes five SLD glass elements. This helps to reduce axial chromatic aberration that cannot be corrected in-camera, allowing the lens to achieve high resolution and clear image quality with no color bleeding.
A high-precision glass molded aspherical lens provides both high resolution and beautiful bokeh. Photographers can enjoy shooting with soft, large bokeh without coloration and this is something that only a full-frame lens is able to deliver.
The lens also utilizes the camera’s optical correction functionality, which is an advantage of mirrorless systems, SIGMA’s optical designers were therefore able to concentrate on correcting aberrations that can only be corrected by the optical design, thereby improving rendering performance and reducing the size and weight of the lens.
With a minimum focusing distance of 50cm and a maximum magnification ratio of 1:5, close-up macro-style photography is possible. The lens highlights the subject, allowing photographers to focus in on fine details or create more abstract compositions.
The AF drive system incorporates a quiet, high-speed stepping motor, making it suitable for still images as well as video recording.

3. Exceptional I series build quality with a compact form-factor

All I series lenses have an all-metal construction. The precision-cut aluminum parts not only give the barrel a sleek, stylish finish, but provide superb durability that improves the quality of the entire product. Metal materials are also used in internal structures that slide with the operation ring for added robustness. These high-precision components crafted with SIGMA’s cutting-edge metalworking technology are also used in SIGMA’s cine lens line-up for professional cinematographers and provide a tactile, ergonomic feel that make the lens a pleasure to use.

The 90mm F2.8 DG DN | Contemporary shares the same φ64mm maximum diameter and 55mm filter size as the 24mm F3.5 DG DN | Contemporary and the 45mm F2.8 DG DN | Contemporary, making them a natural trio, especially for filmmakers who use filters more regularly.
With a combined weight of only 735grams / 25.9oz.*, these three lenses (wide-angle, standard, mid-telephoto) can be used in tandem as part of a high-spec and compact camera system that covers a wide range of shooting situations.
*The figures are for L-Mount.

Additional features

• Lens construction: 11 elements in 10 groups, with 5 SLD and 1 aspherical lens element
• Inner focus system
• Compatible with high-speed autofocus
• Stepping motor
• Compatible with lens aberration correction
* Function available on supported cameras only. Available corrections may vary depending on the camera model.
• Support DMF and AF+MF
• Super Multi-Layer Coating
• Aperture ring
• Focus Mode switch
• Lens hood (LH576-02)
• Magnetic metal lens cap (LCF55-01M)
• Mount with dust and splash resistant structure
• Compatible with SIGMA USB DOCK UD-11 (sold separately / for L-Mount only)
• Designed to minimize flare and ghosting
• Every single lens undergoes SIGMA’s proprietary MTF measuring system
• 9-blade rounded diaphragm
• High-precision, durable brass bayonet mount
• “Made in Japan” craftsmanship
Key specifications (The figures below are for L-Mount)
Lens construction: 10 groups, 11 elements (5 SLD and 1 aspherical) Angle-of-view: 27°
Number of diaphragm blades: 9 (rounded diaphragm)
Minimum aperture: F22
Minimum focusing distance: 50cm
Maximum magnification ratio: 1:5
Filter size: φ55mm
Dimensions (Maximum Diameter x Length): φ64mm×59.7mm. Weight: 295g
